Black and green cable connector with a separate black ring on a white background

TUNGSTEN-CARBIDE-LINED SHORT-VENTURI STYLE | TYP-3 3/16" Orifice 45 cfm

$185.00

The Clemco Part #23501 is a compact, short-venturi abrasive blast nozzle engineered for close-quarters blasting where standard long-venturi nozzles are too unwieldy to maneuver.

  • Model Series: TYP-3 (Short Venturi)
  • Orifice Size: 3/16" (#3)
  • Liner Material: Durable Tungsten Carbide (provides high impact and abrasion resistance with expandable life up to ~300 hours depending on media)
  • Jacket Material: Molded rubber jacket for shock absorption and thread protection
  • Thread Type: 1-1/4" Contractor Threads (1-1/4" NPSM)
  • Air Consumption: 45 CFM at 100 PSI (requires a compressed air supply rated for at least 45+ CFM)
  • Entry Size: 3/4" ID entry
  • Application: Ideal for blast cabinet work, touch-ups, structural steel crevices, and localized spot-blasting where maneuverability takes priority over wide blast pattern coverage.
